TOPIC:

Carb blockage 5 months 2 weeks ago #30817

  • fineline
  • fineline's Avatar Topic Author
  • Offline
  • Premium Member
  • Premium Member
  • Posts: 81
  • Thank you received: 8
That sounds like a possibility Kawboy. I would love to know what really happened. By the way some of the Bracket screws had severe grip marks around the edges, The person certainly didn't have a delicate touch.
Thank heavens for the enrichment mod as I would have thought this carb was junk. At that point I might have tried adding weld, or even welding a nut to the end of it.

Please Log in or Create an account to join the conversation.

Carb blockage 3 weeks 3 days ago #31169

  • Al51boy
  • Al51boy's Avatar
  • Offline
  • New Member
  • New Member
  • Posts: 1
  • Thank you received: 0
Hi, new to this forum so forgive my ignorance but …. I have stripped my carbs, deep cleaned using U/S/C and checked all linkages - all went well until I hade to prove all the jets / ports etc … 3 out of 6 main jet to idle jet “passages“ were blocked
I managed to clear 2 of them using cleaner and compressed air but I’m stumped on the third - everything I try is useless - any tips / ideas?
Cheers


Please Log in or Create an account to join the conversation.

Carb blockage 3 weeks 10 hours ago #31184

  • scotch
  • scotch's Avatar
  • Offline
  • Sustaining Member
  • Sustaining Member
  • Posts: 1856
  • Thank you received: 817
Beg, borrow or steal a Cleaning Tool !
1980 KZ 1300 sr# KZT30A-009997
Always High - Know Fear !

Please Log in or Create an account to join the conversation.

Carb blockage 3 weeks 9 hours ago #31185

  • scotch
  • scotch's Avatar
  • Offline
  • Sustaining Member
  • Sustaining Member
  • Posts: 1856
  • Thank you received: 817
I bought a spare set of carbs as they were going for a reasonable price. They looked very nice.......


Me too !   Took me two weeks also; mostly waiting for some decent weather to bead-blast and paint the bodies.  At least your's had the Diaphragms !
I was also impressed with the condition of these ones.  The original chrome on the hardware cleaned-up nicely and I gave the bowls and lids a "street" polish.  Trying to get a "show" polish is impractical.
  • "Dual fuel-line" just because.  ( Can revert to a single end fuel line ( Right carb) or go back to the original Tee.  I've made some discreet plugs for the carb-ends if other options are desired.)
  • New Brass throughout.
  • Modified Pilot-needles:   (Socket-head conversion and Polished the tips to a point.)
  • Choke-Air mod.
  •  S/S Socket-heads.
  • Enricher mod.
  • Fabricated Diaphragms.  (Anxious to get it on the road to test these.)
  • Polished venturis.  (Interested in whether this detail can squeeze an extra Kilometer or two out of a tank-full.  Currently +52 MPG @ 100KPH)







1980 KZ 1300 sr# KZT30A-009997
Always High - Know Fear !
Attachments:
The following user(s) said Thank You: dcarver220b, zed_thirteen, PaulD

Please Log in or Create an account to join the conversation.

Last edit: by scotch.

Carb blockage 2 weeks 6 days ago #31190

  • biltonjim
  • biltonjim's Avatar
  • Offline
  • Platinum Member
  • Platinum Member
  • Posts: 850
  • Thank you received: 210
It looks like you’ve mounted those beautifully renovated carbs on a plinth as a showpiece.  It’s almost a shame to think of them being hidden away under the tank!

Please Log in or Create an account to join the conversation.

Carb blockage 2 weeks 6 days ago #31191

  • Jafsteph
  • Jafsteph's Avatar
  • Offline
  • Sustaining Member
  • Sustaining Member
  • Posts: 64
  • Thank you received: 19
Yes a fine looking set of carbs

Please Log in or Create an account to join the conversation.
